Product Details:
Imported 0.35 pieces of Nippon Steel or 0.35 pieces of brand new H14 from Japan.Primary and high voltage are wound by automatic winding machines! The secondary filament part is made by a high-power cable laying machine!The Primary design is: 0.76 wire high voltage: 0.40 wire current density 2.5Ah/s design (the wire package is very full).The no-load current is 18MA, and the automatic immersion machine is used for vacuum immersion painting, with a constant temperature of 24 hours for batch baking paint.
Power: 250W
Material: OFC Pure copper
Iron core: Japan imports Nippon Steel iron cores
Primary voltage: AC 220V-230V (50Hz)
Type A
Secondary voltage: 320V - 0 - 320 300mA
0-5V 3A
0-6.3V 3A
0-6.3V 3A
3.15V - 0 3.15V 3A
Type B
Secondary voltage: 380V - 0 - 380 300mA
0-5V 3A
0-5V 3A
0-5V 3A
3.15V - 0 3.15V 3A
Frequency: 50Hz
Size : W 105 L 90 mm H60mm
Weight: about 4.6KG
Package list:
1 × 250W Transformer
