6N1 SRPP+ 6P1 3WX2 Single-ended Class A HIFI DIY stereo tube amplifier

Name: 6N1 SRPP+ 6P1 3WX2 Single-ended Class A HIFI DIY stereo tube amplifier
Brand: BRZ-hifi-audio
SKU: 6N1 SRPP+ 6P1
Price: 201.48 USD
Availability: InStock

Sale

5.0 (2 Reviews)

6 Sold

~~$219.00~~ $201.48

-8%

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (18)

1/1

Description

Features:

A9 has a soft, pure, and round sound, suitable for appreciating vocals, strings, and more.

● Dual channel design, assembly of high-quality resistance and capacitance components.
● Transistor rectification, choke coil, electrolytic capacitor multi-channel filtering.
● German WIMA coupling capacitor
● Silver plated ceramic socket
● Supports 2-channel signal input.
● High precision KOA resistor with 1% error.
● Pure copper enameled wire wound transformer.
● Two 10000uF 50V filtering electrolytic capacitors

Parameters:

● Size: 285 * 275 * 115 cm
● Input voltage: AC220V.
● Output impedance: 0-4-8 Ω
● Output power: 3W+3W
● Weight: about 7kg

List:

1 x 6N1 SRPP+ 6P1 tube amplifier （To ensure safety during transportation, power input cables are not provided by default）
