AD1865 R2R NOS DACFPGA Asynchronous processing technology dual parallel Audiopile decoder

Product details:

AD1865R uses current type pin output, abandoning bulky voltage output mode and adopting dual parallel output mode to increase output power, greatly improving overall performance and listening experience.

Simulated amplification using JRC5532D+JRC5534D.

Power board equipped with ON voltage regulator.

R-type transformer.

Coaxial and USB use FPGA to receive asynchronous clock processing, with a clean sound background and significant improvement in details.

Parameters:

Model: AD1865 PRO

Product size: 280 * 200 * 50mm

Weight: 2.5kg

Input: USB (Amanero USB iis asynchronous digital interface)

SPDIF (FPGA Asynchronous Reception)

Output: RCA single ended 1.5vrms

DAC CHIP: AD1865R

Input format support: SPDIF pcm44.1~384khz

USB pcm44.1~384kHz

DSD format not supported

DAC design adopts NOS structure and current mode output.

List：

AD1865 decoder x 1
