Dual UV meter 6H2N+6n1n+6Z4 tube power amplifier ,high-frequency transparent, medium-frequency round, very good sound

Dual UV meter 6H2N+6n1n+6Z4 tube power amplifier ,high-frequency transparent, medium-frequency round, very good sound

The amplifier is upgraded!

Bile refers to the electronic tube. The tube amplifier, which is often referred to, refers to the amplifier of the electronic tube. Some electron tubes are used for amplification and some are used for polishing. The tube amplifier has his unique "guts", the sound is warm and durable, the music feels good, and the atmosphere is good. The tube amplifier is the oldest and enduring evergreen tree in the audio industry. Its remarkable advantage is that the sound is sweet and soft, and the natural concern, Especially the large dynamic range and good linearity, cannot be easily replaced by other devices.

Features of this machine: high-frequency transparent sound, mellow mid-frequency, soft and natural low-frequency, full of charm.

This shop is based on the principle of convenience for enthusiasts first and profit second. Since the baby is on the shelves, it has been supported by many enthusiastic players. Here, the shopkeeper sincerely thanks everyone for your support. Without your support, there would be be no such thing as a dragon and phoenix! At the same time, many enthusiasts have also put forward a lot of valuable opinions, we will accept them with an humility and make continuous efforts to improve.

The cattle used in the kit are all single crystal copper cattle, and the silicon steel sheet is a brand-new WISCO special-grade steel single chip with a transparent and beautiful tone. Coupling capacitors are German Red Celestial WIMA Weimar fever capacitors, and other accessories are all new well-known brand accessories (capacitor brands are Japanese Black King Kong, Japanese Nichicon, Korea Sanhe, Taiwan Lilong, etc.). The electronic tube is a new stock tube, and the brands are Shanghai, Beijing, and Shuguang , etc., are shipped randomly. Welcome all fans to come and taste. (Friendly reminder: The case is DIY and has many holes and many processes, so scratches and dents are unavoidable during the processing process. If you mind, please don' t take pictures) The following is the display

The kit list is as follows: Chassis*1

Chassis feet*4

Bottom plate*1

Several self-tapping screws

One power transformer

Primary: 230v-0v 0.15a/Secondary: 240v-0v 3.15v-0v-3.15v 3a 76*50 Power 100W (rated power 85W)

Two output transformers (primary 5k/secondary: 0-4Ω-8Ω/output power 5W/special chip)

Signal input socket*2

Output terminal *6

Power socket*1 (including fuse)

Power cord (provided by yourself, is the power cord on the computer)

Switch*1

Potentiometer 100K*1

Potentiometer knob*16Z4 tube*2

6N2 tube*1

6P1 tube*2 small seven-pin tube socket*2

Small nine-pin tube socket*3

0.33uf/450v *2

100uf/35v*2

220uf/450v*2

33uf/250v*2

150k*2

2k*2

36k*2

18k*2

470K*2

240Ω*4 5W

Double-core shielded wire 30cm

Casing 15cm

Welding line 2m

3mm 4mm female screws
