Product Details:
True signal balanced input and balanced output. Balanced transmission allows for lower distortion and better dynamics. Balanced input and output ports, plus a standard RCA input and a standard 6.5MM headphone jack single-ended output, which is very compatible. The output chip uses TI high-end headphone amplifier chip TPA6120, TPA6120A2 is a current feedback type amplifying circuit. With a safety protection circuit, the two-way relay monitors the working status of the left and right channels. Use Audio filter capacitor, WIMA coupling capacitor, Japan ALPS 4 potentiometer, Swiss Nutrik gold-plated balanced terminal. The JRC5532DDop amp is used by default. (Customers can freely change other dual op amps) Use an all-aluminum chassis Perfect UPC1237 protection circuit High speed and high power linear regulated power supply system
Specifications:
Working voltage: AC110V or AC220V Input port: RCA input, balanced input Output: L/R balanced output, 6.5MM headphone jack Net weight: 1.92KG Dimensions (W*H*D): 250MM*55MM*165MM
Package list:
1 × Finished headphone amplifier
