FM610MAX dedicated 450W EI transformer Carefully wound with oxygen-free copper wire

Product Details:

Using Japan's brand-new Z11 0.35 steel sheet, carefully wound with oxygen-free copper wire, it features no vibration, no noise, and no heat generation. When used with the FM610MAX power amplifier board, the sound background is clean, the layers are distinct, with sustained power and strong explosiveness, resulting in excellent performance.

Power: 450W

Material: OFC Pure copper

Iron core: Japan Z11 0.35 steel sheet

Primary voltage: AC 0-230V (50Hz)

Secondary voltage: AC58V - 0 - 58V   0-13V     0-13V

No-load current: 35mA, primary DC resistance: 3.5 ohms

Size  :  W 123 L123 H120mm

Weight: 7.35KG


Package list:

1 × 450W Transformer
