Product Details:
The FM original parameter core circuit has completely independent left and right channels, paired with MBL preamp circuit, parallel regulated power supply, reasonable layout, stable performance, and no noise Deeply loved by Audiophiles.
16 newly tested paired (<1%) transistors 2N3440/5416.
Test pairing of 28 units per group (<1%) of the all-new Toshiba 5200 from Japan requires selecting from thousands of units
Each high-power transistor is connected in parallel with decoupling capacitors and decoupling electrolytic capacitors.
800w high-quality Nippon Steel transformer with independent winding for left and right channels.
80000uF ELNA FOR AUDIO High Quality Capacitor
Soft start and complete horn protection circuit during startup.
CNC precision machining of all aluminum chassis with CNC machine tools.
ALPS27 volume potentiometer.
Super single operation OPA828 for preamp amplification and gold-plated IC socket.
CMC pure copper platform produces high-quality RCA
Parameters:
Output effective value: 40.5Vrms
Channel gain: 42.2dB 129.5 times
Signal to noise ratio: 103dB
Dynamic range: 103db
THD distortion: 0.002%
THD+N distortion: 0.004%
Intermodulation distortion: 0.005%
Frequency response bandwidth: ± 0.016dB
Weight: 22KG
Static power consumption: 110W
Size: 450 * 362 * 155mm
Package list:
1 × FM801 circuit amplifier（For the safe transportation of the amplifier, a power cord is not provided by default）
