Product details:
1mm thickness steel plate black spray process box.
use of 8mm thick aluminum wire drawing process panel.
Aluminum alloy knob, high grade, good hand feel.
Blue power indicator light.
Low magnetic leakage Toroidal transformer power supply.
Shielded signal input cable.
Audio capacitors from well-known brands such as WIMA in Germany.
The preamp signal is amplified using 6J1 electronic tubes, which provide clear and beautiful sound with low distortion.
LM1876T power amplifier chip with protective circuit..
The electronic tube preamp adopts a stable power supply, and the noise level will be minimized.
The filament adopts AC power supply and balanced grounding, with a warm and smooth sound.
Parameter :
Maximum output: 2×30W ( 8ohm)
Input Impedance: 100Kohm
Output Impedance: 4ohm 8ohm
Input Sensitivity: 500 to 2000mV
Total Hamonic Distortion: less than 0.1%(1kHz)
Frequeney responses: 20Hz-30KHz1dB
Signal to Noise Ratio: 90dB
Chip: LM1876T
Power tubes: 6J1×2pcs
Input voltage: 110/220V 60Hz/50Hz 220V version are in stock
Dimensions: 185mm(W)×80mm(H)×270mm(L)
Package size:210mm(W)×118mm(H)×290mm(L)
Net weight:3.5KG
Gross weight: 4.5KG
List：
H-06A amplifier x 1
