Product Details

AD1852 chip quality and sense of hearing coexist. It is adopted by many professional decoders. The sound is neutral. It is very mellow and dynamic, and the degree of completion is very high. This is the cost-effective decoder of our store.

Use AD1852 decoding chip.

All aluminum housing.

Using PCM2706 USB subcard.

PCM2706 USB is stable and mature.

Not using HOST power supply method, the power supply is stabilized to improve stability.

An active crystal oscillator provides a stable clock.

SPDIF output level waveform shaping.

PCM2706 USB Support frequency: 44.1K, 48K. Bit width: 16 Bit.

Specifications

Digital input: coaxial, optical, USB

Analog output: RCA analog output.

Digital input bit rate: 16~24Bit, 44.1~192K.

Line output level: >2Vpp.

Power supply: AC220V or AC110V (Optional)

Dimensions (W*H*D): 116*50*188MM

Net weight: about 0.8KG

Package List

1 × AD1852 Audio Decoder DAC

Note: AC power cord not included.
