IRAUD200 amplifier has a very balanced sound, strong and powerful bass, dive deep, alto sweet, treble clear, extending well. Whether it is bookshelf box or floor box, can easily cope with a small size, high efficiency, high power and so on.
Specifications:
Model: IRAUD200
Channel: 2
Output power: 500W
Size: 130mm × 75mm × 60mm
Weight: 250g
Impedance: 4Ω / 8Ω
Use voltage range: DC ± 26 to ± 80V, the proposed use of AC voltage 75V below, because the mains voltage will fluctuate, you need to leave some margin Caixing.
Maximum output power: 350W / 8Ω distortion <0.1%
(± 80V power supply) 700W / 4Ω distortion <0.1%
Overvoltage protection value: ± 84V
Voltage magnification: 40 times
Input sensitivity: 1.5V (rms)
Input impedance: 5KΩ
Frequency response: 0-50KHz ± 3dB 10W / 8Ω
Remaining noise voltage: 200uV
Dynamic range:> 100dB
Efficiency: Class D power amplifier efficiency is very high, of course, different efficiency of different output power, high efficiency, high efficiency, 200W / 8Ω output to reach more than 93%.
