This preamplifier boasts high resolution, precise soundstage imaging, rich detail, wide frequency response, low distortion, warm sound, and strong control.
● 6X4 rectification, using LM317 as a delayed power supply for the filament ● This preamp has delayed output, which can effectively protect your amplifier and audio . ● All aluminum alloy chassis with heat dissipation slots on both sides for good heat dissipation effect. ● Japanese ALPS27 potentiometer ● Taiwan made all copper RCA ● Oxygen free copper signal cable. ● Famous brand audio capacitor. ● The signal-to-noise ratio is extremely high, and the noise is almost inaudible. ● KOA audio resistor ● Equipped with relay output protection
Parameters:
● Size: 240*320*90 mm ● Input voltage: AC220/110V. ● Frequency response: 10Hz-30KHz ● Weight: 4.36kg ●Distortion: 0.038% ● Magnification factor: 20x ● Maximum output: 22.63V ● Signal to noise ratio: 99dBu ● Minimum input: 1.3mV ● Output impedance: 600 Ω ● Frequency response bandwidth: ± 0.053db 20-20KHz completely flat
List:
1 x Kondo G-1000 preamplifier（To ensure the safety of the product during transportation, a power input cable is not provided by default）
