Product Details:
S11 is a high-performanceDIY single-rail linear regulated power supply (PSU). It isbasically half the dual-rail PSU 22, and possesses the same low-noise, high-current,excellent line/load regulation, wide-bandwidth, and stabilitycharacteristics.S22 is ideal for DIY stereo headphone amplifiers,preamplifiers, DACs, network media players, and other applicationsrequiring a single-rail regulated PSU.
The circuit uses all discrete components (no integrated circuits),and features high-current MOSFETs as theoutput "pass" devices.
S11 is derived from the 22, which is the result ofa community service project for theaudiophile hobbyist. The schematic diagram is open source.The circuit design, as well as the printed circuit boardlayout are the work of AMB with participation from the DIY community.It is designed to be relatively easy to build, but it is notrecommended as a first-time project for the beginner.
PCB size: 102X86mm
we can provide DC5V / 9V / 12V / 15V / 18V / 21V / 24V version for choose. ( the output voltage can minute adjustment
Please tell us which version is you need!!
we also can accept custom-make other output voltage.
S11max Output Current 30A.
The input AC voltage recommned higher 3-5V than the output DC voltage. (for example. if you need DC12V voltage output, the input AC recommned 15V.)
All the components are using the high end parts.
Package List:
1 × S11 power supply board
