Refer to Matisse Fantasy Circuit HIFI DIY stereo Electronic Tube Preamplifier

Product Details:


This preamp has a sweet and delicate sound, excellent control, and good high and low frequency extension .

All aluminum alloy chassis, with surface oxidation and wire drawing treatment.

Built in high voltage regulator circuit, using 6X4/6Z4 electronic tube rectification.

Designed with delayed output function, effectively protecting your device from impact.

Taiwan made pure copper RCA.

Japanese ALPS27 volume potentiometer.

The signal-to-noise ratio is high, and the noise is almost inaudible.

Parameter:

Input voltage: AC 115V or 230V (Optional)

Frequency response: 10Hz-30KHz
Distortion: 0.014%
Magnification factor: 12 times
Maximum output: 28V
Signal to noise ratio: 102db
Minimum input: 1mv

Size: W240mm*H90mm*D320mm (Excluding machine feet and various protruding positions)

Weight: About 4.36KG
Electronic tube model: 6Z4 *      6U8A * 1  /   6X4 *      6U8A * 1

Package include:

Matisse Fantasy Circuit tube amplifier   X 1 (NO IEC type mains power cable included)

Every amp has been professionally tested in perfect working order before shipping!
