This radio frequency amplifier is a linear power amplifier, which has the characteristics of small distortion and wide frequency range, and can be applied to various forms of signal amplification. Such as tpms transmission, wireless charging and other communications or remote control, etc., act as the final power amplifier to enhance the transmission power and increase the transmission distance. This long wave, medium wave and high frequency amplifier can be used in universities, scientific research institutes and radio enthusiasts. The main parameters of the amplifier:
1 Amplifier frequency 100kHz—3MHz
2 Single power supply voltage 48V (if you need other power supply voltage values, please contact the store owner)
3 The amplifier gain is about 47dB. That is, the input is about 0dBm (1mW) and the output is 50W.
4 Input and output impedance 50 ohms
5 Input and output connector SMA (female)
6 Overall dimensions: 103×90×83mm3 (excluding input and output SMA connectors and power connectors)
If you need a more powerful amplifier, please contact customer service.
Wide frequency range for versatile applications This power amplifier supports frequencies from 100kHz to 3MHz, making it ideal for long wave, medium wave, high frequency, and ultrasonic signal processing in various electronic projects.
High power output for efficient performance With a rated power of 50W, this amplifier delivers strong signal amplification, ensuring reliable operation in demanding home DIY and RF applications.
Durable aluminum-copper alloy construction Built with a robust aluminium-copper alloy material, this component offers excellent heat dissipation and mechanical strength for long-term reliability under continuous use.
Compact and lightweight design for easy integration Measuring 18 x 15 x 15 cm and weighing only 0.680 kg, the package is compact and lightweight, making it easy to store, transport, and integrate into DIY setups.
Single-piece packaging for straightforward use Sold as 1 piece per pack, this amplifier is perfect for users needing a direct replacement or a dedicated component without excess inventory.
